BAT721X

Preliminary

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R601-258.c



PARAMETER

SYMBOL

RATINGS

UNIT

Continuous Reverse Voltage

40

V

Continuous Forward Current

200

mA

Non-Repetitive Peak Forward Current

(half sine wave; JEDEC method; tp = 8.3 ms)

1000

mA

Operating Junction Temperature

+125

°C

Storage Temperature

-65~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL CHARACTERISTICS

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

500

K/W

Notes: Device mounted on an FR4 Printed-Circuit Board (PCB), single-sided copper, tin-plated and standard

footprint.



PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Continuous Forward Voltage (Note 1)

300

mV

420

mV

550

mV

Continuous Reverse Current (Note 1)

15

μA

3

mA

Diode Capacitance (Note 2)

40

50

pF

Notes: 1. Pulse Test: Pulse Width = 300µs, Duty Cycle ≤ 2.0%.

2. Measured at 1MHz and applied reverse voltage of 4.0V D.C.
