UNISONIC TECHNOLOGIES CO., LTD

BAV20W

Preliminary

DIODE

www.unisonic.com.tw

1 of 3

QW-R601-205.b

SILICON EPITAXIAL PLANAR

DIODE



DESCRIPTION

The UTC BAV20W is a silicon epitaxial planar diode. The UTC

BAV20W

is suitable for general purpose application.



FEATURES

* Planar diode

* For general purpose application

* Low leakage current

SOD-323

SOD-123

2

1

2

1



ORDERING INFORMATION

Ordering Number

Package

Pin Assignment

Packing

1

2

BAV20WG-CA2-R

SOD-123

K

A

Tape Reel

BAV20WG-CB2-R

SOD-323

K

A

Tape Reel

Note: Pin Assignment: A: Anode

K: Cathode

(1) R: Tape Reel

(2) CA2: SOD-123, CB2: SOD-323

(3) G: Halogen Free and Lead Free

BAV20WG-CA2-R

(1)Packing Type

(2)Package Type

(3)Green Package



MARKING
