SB120

Preliminary

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R601-277.b



ABSOLUTE MAXIMUM RATINGS (TA=25°C unless otherwise specified)

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitance load, derate current by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

Peak Repetitive Reverse Voltage

VRRM

Working Peak Reverse Voltage

VRWM

RMS Reverse Voltage

VR(RMS)

DC Blocking Voltage

Average Rectified Output Current

1.0

Non-Repetitive Peak Forward Surge Current 8.3ms

Single Half Sine-Wave Superimposed on Rated Load

(JEDEC Method)

IFSM

Operating Junction Temperature

-65~+125

°C

Storage Temperature

TSTG

-65~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

SMA

°C/W

Junction to Ambient

DO-41

θJA

°C/W



ELECTRICAL CHARACTERISTICS (Note 2) (TA =25°C unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Reverse Breakdown Voltage

V(BR)R

IR=0.50mA

Forward Voltage Drop

VFM

IF=1.0A

0.45

TA=25°C

1.0

Peak Reverse Current

at Rated DC Blocking Voltage

IRM

TA=100°C

Notes: 1. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.

2. Short duration test pulse used to minimize self-heating effect.
