background image
BAV199W
DIODE
UNISONICTECHNOLOGIESCO.,LTD
2 of 3
www.unisonic.com.tw
QW-R601-045.C
ABSOLUTE MAXIMUM RATINGS (TA = 25°C, unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Peak Repetitive Reverse Voltage
VRRM
85
V
Working Peak Reverse Voltage
VRWM
85
V
DC Blocking Voltage
VR
85
V
RMS Reverse Voltage
VR(RMS)
60
V
Forward Continuous Current
Single diode
IFM
160
mA
Double diode
140
Repetitive Peak Forward Current
IFRM
500
mA
Non-Repetitive Peak Forward
Surge Current
@ t = 1.0μs
IFSM
4.0
A
@ t = 1.0ms
1.0
@ t = 1.0s
0.5
Power Dissipation (Note 2)
PD
250
mW
Junction Temperature
TJ
-65~+150
°C
Storage Temperature
TSTG
-65~+150
°C
Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2. Part mounted on FR-4 PC board with recommended pad layout.
THERMAL DATA
PARAMETER
SYMBOL
RATINGS
UNIT
Junction to Ambient (Note 2)
θJA
500
°C/W
ELECTRICAL CHARACTERISTICS (TA =25°C, unless otherwise specified.)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN TYP MAX UNIT
Reverse Breakdown Voltage (Note)
V(BR)R
IR= 100μA
85
V
Forward Voltage (Note)
VF
IF= 1.0mA
0.90
V
IF= 10mA
1.0
IF= 50mA
1.1
IF= 150mA
1.25
Leakage Current (Note)
IR
VR= 75V
5.0
nA
VR= 75V, TJ= 150°C
80
Total Capacitance
CT
VR= 0, f = 1.0MHz
2
pF
Reverse Recovery Time
trr
IF= IR= 10mA, Irr = 0.1 x IR,RL= 100Ω
3.0
μs
Note: Short duration test pulse to minimize self-heating effect.
