MBR1060C

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R601-019. E



PARAMETER

SYMBOL

RATINGS

UNIT

Maximum Repetitive Peak Reverse Voltage

60

V

Maximum DC Blocking Voltage

60

V

Working Peak Reverse Voltage

60

V

Maximum PMS Reverse Voltage

42

V

Average Forward Rectified Output

Per Leg

5

A

Total

10

Non-Repetitive Peak Forward Surge Current 8.3ms Single

Half-Sine-Wave

125

A

Typical Junction Capacitance (Note 4)

150

pF

Operating Temperature

-55 ~ +150

°C

Storage Temperature

-55 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

60

°С/W

Junction to Case

TO-220/TO-263

3

°С/W

TO-220F/TO-220F1

5

°С/W



ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Instantaneous Forward Voltage Drop (Note 2)

0.80

V

0.70

V

0.95

V

0.90

V

Instantaneous Reverse Current (Note 2)

100

μA

15

mA

Notes: 1. 2.0μs Pulse Width, f = 1.0 KHz.

2. Pulse Test: Pulse Width = 300µs, Duty Cycle ≤ 2.0%.
