LM26

www.ti.com

SNIS115S – MAY 2001 – REVISED SEPTEMBER 2015

7.2 ESD Ratings

VALUE

UNIT

Human body model (HBM)

±2500

V(ESD)

Electrostatic discharge(1)

Machine Model

±250

(1)

The human body model is a 100-pF capacitor discharge through a 1.5-k

Ω resistor into each pin. The machine model is a 200-pF

capacitor discharged directly into each pin.

7.3 Recommended Operating Conditions

over operating free-air temperature range (unless otherwise noted)

(1)

MIN

MAX

UNIT

Specified Temperature Range (TMIN ≤ TA ≤ TMAX)

−55

125

°C

Positive Supply Voltage (V+)

2.7

5.5

Maximum VOUT

5.5

(1)

Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for

which the device is functional, but do not guarantee specific performance limits. For guaranteed specifications and test conditions, see

the Electrical Characteristics. The guaranteed specifications apply only for the test conditions listed. Some performance characteristics

may degrade when the device is not operated under the listed test conditions.

7.4 Thermal Information

LM26

THERMAL METRIC(1)

DBV (SOT-23)

UNIT

5 PINS

RθJA

Junction-to-ambient thermal resistance

250

°C/W

(1)

For more information about traditional and new thermal metrics, see the Semiconductor and IC Package Thermal Metrics application

report, SPRA953.

7.5 Electrical Characteristics

The following specifications apply for V

+ = 2.7 V

DC to 5.5 VDC, and VTEMP load current = 0 µA unless otherwise specified. All

limits apply for TA = TJ = TMIN to TMAX unless otherwise specified.

PARAMETER

TEST CONDITIONS

MIN(1)

TYP(2)

MAX(1)

UNIT

TEMPERATURE SENSOR

Trip Point Accuracy (Includes VREF, DAC,

–55°C

≤ TA ≤ +110°C

±3

°C

Comparator Offset, and Temperature

TA = +120°C

±4

°C

Sensitivity errors)

HYST = GND

°C

Trip Point Hysteresis

HYST = V+

°C

VTEMP Output Temperature Sensitivity

−10.82

mV/°C

VTEMP Temperature Sensitivity Error to

−30°C ≤ TA ≤ 120°C

±3

°C

Equation:

−55°C ≤ TA ≤

4.5 V

≤ V+ ≤ 5.5 V

±3

°C

VO = (−3.479 × 10

−6 × (T − 30)2) +

120°C,

(

−1.082 × 10−2 × (T − 30)) + 1.8015 V

TA = 30°C

±2.5

°C

Source

≤ 1 μA

0.070

VTEMP Load Regulation

Sink

≤ 40 μA

0.7

+2.7 V

≤ V+ ≤ +5.5 V,

VTEMP Line Regulation

−0.2

mV/V

−30°C ≤ TA ≤ +120°C

TA = 25°C

µA

Supply Current

(1)

Limits are guaranteed to TI's AOQL (Average Outgoing Quality Level).

(2)

Typicals are at TJ = TA = 25°C and represent most likely parametric norm.

Submit Documentation Feedback

Product Folder Links: LM26
