1 / 1 page

MLPC12-R47M-RC

.47

20

3 MHz, 200mV

0.06

1600

Rated Current

Max. (mA)

Allied

Part

Number

Inductance

(

µh)

Tolerance

(%)

Test

Freq.

(MHz)

DCR

Max.

(Ω)

MLPC12-1R5M-RC

1.5

20

3 MHz, 200mV

0.11

1200

MLPC12-1R0M-RC

1.0

20

3 MHz, 200mV

0.09

1300

MLPC12-R56M-RC

.56

20

3 MHz, 200mV

0.07

1500

All specifications subject to change without notice.

Multilayer Power Chip Inductor

MLPC12

15

ALLIED COMPONENTS INTERNATIONAL

949-356-1780

www.alliedcomponents.com

RoHS

08/26/14

Dimensions:

Inches

(mm)

Features

• 0806 EIA Size

• Multilayer Ferrite Construction

• High Current Capacity

Electrical

Inductance Range: .47µh ~ 4.7µh

Tolerance: 5% across entire range

Test Frequency: 3MHZ, 200mV

Operating Temp: -55ºC ~ 125ºC

Rated Current: Based on a temp rise of

no more than 40ºC

Resistance to Soldering Heat

Pre-heating: 150ºC, 1min

Solder Composition: Sn/Ag3.0/Cu0.5

Solder Temperature: 260 ± 5ºC

Test Equipment

(L):

HP4291A RF Impedance Analyzer

DCR: Chen Hwa 502 BC

IDC:

HP4284A with HP42841A /

Physical

Packaging: 3000 pieces per 7 inch reel.

Marking: None

Also available in 10% & 20%

Immersion Time: 10 ± 1sec

HP4285A with HP42841A

• Excellent Solderability Characteristics

No Damage with more than 75% coverage

Inductance within 20 of initial value.

MLPC12-4R7M-RC

4.7

20

3 MHz, 200mV

0.21

800

MLPC12-3R3M-RC

3.3

20

3 MHz, 200mV

0.17

850

MLPC12-2R2M-RC

2.2

20

3 MHz, 200mV

0.13

1000

0.049±0.008

(1.25±0.20)

0.079±0.008

(2.0±0.2)

0.02±0.012

(0.5±0.3)

.04 MAX

(1.0 MAX)

0.049±0.008

(1.25±0.20)

0.063±0.008

(1.6±0.20)

Recommended Pad Layout

0.083±0.106

(2.1~2.7)

0.031±0.047

(0.8~1.2)

0.063±0.079

(1.6~2.0)
