SMD High Current Shielded Choke

PCHC412R8L

15

ALLIED COMPONENTS INTERNATIONAL

949-356-1780

www.alliedcomponents.com

RoHS

07/29/2015

Features

• Magnetically shielded construction

Electrical

Inductance Range:

1.0uH additonal

Tolerance:

20% over entire range

Operating Temp:

-55ºC ~ +125ºC

Pre-Heat 150ºC, 1 minute.

Test Equipment

(L):

WK 3260B

• Ultra High saturation current up to 6.0A

Resistance to Soldering Heat

Solder Composition:

Sn/Ag3.0/Cu0.5

Solder Temp:

260ºC ± 5ºC

DCR:

Chen HWA502

Irms:

Test Frequency

: 100KHz, 0.5Vdc

• Low DC Resistance

• Expanded operating temp range

Immersion Time:

10 sec. ± 1 sec.

.162+/-.008

(4.1+/-0.2)

(4.6±0.2)

.181±.008

(1.2)

.047

(1.5±0.3)

.06±.012

.04+/-.02

(1.0+/-0.5)

no more than 30% from initial value without current.

• Suitable for pick and place

values available.

Under no condition should the temperature of the part

Physical

Packaging:

2000 pieces per 13 inch reel.

Marking:

EIA Inductance Code

IDC:

3260B WK & DC Bias 3265B WK

All specifications subject to change without notice.

Allied

Part

Number

Inductance

(

µH)

Irms (A)

Max(Typ)

Test

Frequency

(KHz, 0.5V)

Tolerance

(±%)

RDC(mΩ)

PCHC412R8L-1R0M-RC

Isat (A)

1.0

35(32)

20

100

6.0(6.5)

4.5(5.0)

(Recommended Pattern)

.098

(2.5)

.059

(1.5)

.146

(3.7)

Max(Typ)

by 40ºC from Abmient without current.

0.0

0.2

0.4

0.6

0.8

1.0

1.2

0

1

23456

7

DC Current(A)

0

20

40

60

80

100

L(uH)

△T(℃)

Graph:

The current at which the Temp will rise

Isat:

The current at which the inductance will drop by

exceed 125ºC.

*Photo for reference only.

Dimensions:

Inches

(mm)

MAX
