Page 2
ams Datasheet
Document Feedback
[v1-01] 2015-Oct-12
AS-MLV-P2 − Pin Assignment
Figure 2:
Pin Diagram
Figure 3:
Pin Description
Pin Number
Pin Name
Description
1
RS1
Sensor electrode 1
2
RH1
Heater 1
3
RS2
Sensor electrode 2
4
RH2
Heater 2
Pin Assignment
1
2
4
3
Pin 1 Indicator
