ADP1290

Data Sheet

CH1 2.00V BW

CH3

1.00AΩ BW

CH2 5.00V BW M400µs

A CH4

1.04V

T 10.40%

INPUT CURRENT

OUTPUT

Figure 16. Typical Turn On Time and Inrush Current, VIN = 13.2 V,

COUT = 100 μF, RLOAD = 100 Ω

CH1 2.00V BW

CH3 50.0mAΩ BW

CH2 1.00V BW M400µs

A CH4

1.04V

T 10.40%

Figure 17. Typical Turn On Time and Inrush Current, VIN = 2.3 V,

COUT = 10 μF, RLOAD = 100 Ω

CH1 2.00V BW

CH3 100mAΩ BW

CH2 2.00V BW M400µs

A CH4

1.04V

T 10.40%

INPUT CURRENT

OUTPUT

Figure 18. Typical Turn On Time and Inrush Current, VIN = 6.5 V,

COUT = 10 μF, RLOAD = 100 Ω

CH1 2.00V BW

CH3

200mAΩ BW

CH2 5.00V BW M400µs

A CH4

1.04V

T 10.40%

INPUT CURRENT

OUTPUT

Figure 19. Typical Turn On Time and Inrush Current, VIN = 13.2 V,

COUT = 10 μF, RLOAD = 100 Ω

Rev. 0 | Page 8 of 12
