Photoelectric sensors

G10, Photoelectric proximity sensor, energetic

1) 2) Object with 90 % reflectance (referred to standard white, DIN 5033) 3) Average service life: 100,000 h at TU = +25 °C

Type

> GTE10-R3821

Part No.

> 1065874

At a glance

Long sensing ranges: up to 2,000 mm

•

PinPoint LED with bright and precise light spot

•

Immunity to ambient light

•

10 V DC ... 30 V DC or 24 V AC/DC … 240 V AC/DC power supply with

PNP/NPN or relay output

•

Small housing design

•

Rugged sensor housing with metal-reinforced holes for assembly

•

Q-Lock assembly system for mounting and aligning the sensor within a few

seconds

•

Your benefits

Long sensing ranges for maximum operating reserves

•

Efficient installation: the GTE10 and the Q-Lock assembly system save valuable

hours when mounting and commissioning multiple sensors

•

Universal DC or AC/DC power supply for even greater application flexibility

•

Highly reliable and durable despite optical interference or mechanical loads

•

Wide range of accessories simplifies sensor integration: aids for assembly and

connectors

•

Illustration may differ

Features

Sensor/detection principle:

Photoelectric proximity sensor, energetic

Dimensions (W x H x D):

20 mm x 50 mm x 51.5 mm

Housing design (light emission):

Rectangular

Sensing range max.:

Sensing range:

Type of light:

Infrared light

Light source:

Wave length:

850 nm

Adjustment:

Potentiometer, 270°

Light spot size (distance):

Ø 57 mm (1,500 mm)

Mechanics/electronics

Supply voltage:

Ripple:

Power consumption:

≤ 2.5 VA
