DocID028515 Rev 1
7/58
STCOM
Description
58
1.1
Device architecture
The architecture is composed of the following parts:
1.
PLC front-end including digital front-end and analog front-end
2.
PLC line driver
3.
Real-time engine: the digital core running the lower layers of the PLC protocol stack
and implementing modulation and demodulation
4.
Protocol engine: the main digital core for running the upper layers of the PLC protocol
stack
5.
Wide range of peripherals logically divided into 4 blocks:
–
Basic peripherals
–
Com1 peripherals
–
Com2 peripherals
–
Crypto peripherals.
The STCOM detailed architecture is shown in Figure 2.
