JH24240320C
VER: 03.1
- 11 -
Issue date: 2013/08/01
JEWEL HILL ELECTRONIC CO.,LTD.
8.MCU Interface Pin Function
Pin NO.
Symbol
Description
1
GND
Power Ground
2
YD
TOUCH PANEL Y_ DOWN
3
XL
TOUCH PANEL X_ LEFT
4
YU
TOUCH PANEL Y_ UP
5
XR
TOUCH PANEL X_ RIGHT
6
LCD-IN
NC
7
VCC
The
power supply 2.8V
8
IOVCC
Power supply For logic(1.8-2.8V)
9
FMARK(TE)
NC
10
CS
Chip Select
11
RS
Command/display data select pin
12
WR
Write signal
13
RD
Read signal
14-29
D0-D15
Data bus
30
RESET
Reset Pin
31
IM0
80 -16bits/80- 8bits select pin
32
NC
NC
33
GND
Power Ground
34
LEDK1
Backlight
Power(cathode)
35
LEDK2
Backlight
Power(cathode)
36
LEDK3
Backlight
Power(cathode)
37
LEDK4
Backlight
Power(cathode)
38
LEDA
Backlight
Power(ande)
39
GND
Power Ground
40
NC
NC
