12 / 25 page  JH24240320A VER: 0.1 - 11 - Issue date: 2013/08/01 JEWEL HILL ELECTRONIC CO.,LTD. 7.INTERFACE DESCRIPTION. Pin NO. Symbol Description 1 GND Power Ground 2 VCI The power supply 2.8V 3 VDD The power supply 2.8V 4 CS CHIP SELECT PIN 5 RS Command/display data select pin 6 /WR/SCL Write enable clock input pin 7 RD Read enable clock input pin 8 SDI Serial data input pin 9~26 D0~D17 Data Bus 27 ENABLE A data ENABLE signal in RGB I/F mode 28 DOTCLK Data enable signal in RGB interface 29 HSYNC Horizontal synchronizing signal in RGB interface 30 VSYNC Vertical synchronizing signal in RGB interface 31 RESET Reset Pin 32 IM3 Interface Mode Select 33 IM2 Interface Mode Select 34 IM1 Interface Mode Select 35 IM0 Interface Mode Select 36 LED_A LED+ 37 LED_K1 LED- 38 LED_K2 LED- 39 LED_K3 LED- 40 LED_K4 LED- 41 SDO NC 42 XL TOUCH PANEL X_ LEFT 43 YU TOUCH PANEL Y_ UP 44 XR TOUCH PANEL X_ RIGHT 45 YD TOUCH PANEL Y_ DOWN |
|
|
