JH26240320C

VER: 1.0

- 3 -

Issue date: 2013/08/12

JEWEL HILL ELECTRONIC CO.,LTD.

1. GENERAL DESCRIPTION.

JH26240320C model is a Color TFT LCD. This main Module has a 2.6 inch diagonally

measured active display area with 240(RGB)×320 resolution. Each pixel is divided into Red,

Green and Blue sub-pixels and dots which are arranged in vertical stripes.

The LCD color is determined with 262,000 colors signal for each pixel.

The JH26240320C has been designed to apply the interface method that enables low

power, high speed, and high contrast.

The JH26240320C is intended to support applications where thin thickness, wide viewing

angle and low power are critical factors and graphic displays are important.

2. GENERAL FEATURES.

Item

Display Panel

Remark

Display Mode

Normally White, Transmissive LCD

Viewing Direction

12 O’CLOCK

Input Signals

8-Bits

Outside Dimensions

46mm(W)*64mm(H)*2.2mm(T)

Effective Area

-

Active Area

38.88mm(W)×51.84mm(H)

Number of Pixels

240×RGB×320Pixels

Pixel Pitch

0.162mm(H)×0.162mm(W)

Pixel Arrangement

RGB Vertical stripes

Drive IC

RM68090

3.Absolute Maximum Ratings

The following are maximum values which, if exceeded may cause operation or damage to

the unit.

ITEM

Symbol

Min.

Typ.

Max.

Unit

Remark

Power for Circuit Driving

VDD

-0.3

-

3.3

V

Power for Circuit Logic

VCI

-0.3

-

4.6

V

LC Operating Voltage *1)

Vop

-

V

LED Forward Voltage

V

BBBBBBBBB

f

BBBBBBBBB

3.0

3.2

3.4

V

LED Forward Current

If

-

60

-

mA

LED Luminance

B

BBBBBBBBB

P

BBBBBBBBB

3200

-

-

cd/m

PPPPPPPPP

2

PPPPPPPPPPPPPPPPPPPPPPP

Storage Humidity

H

BBBBBBBBB

ST

BBBBBBBBB

10

-

90

%RH

Storage Temperature

T

BBBBBBBBB

ST

BBBBBBBBB

-30

-

80

℃

Operating Ambient Humidity

H

BBBBBBBBB

OP

BBBBBBBBB

10

-

90

%RH

Operating Ambient temperature

T

BBBBBBBBB

OP

BBBBBBBBB

-20

-

70

℃

At

25±5℃
