JH30240400A

VER: 0.1

- 3 -

Issue date: 2013/08/01

JEWEL HILL ELECTRONIC CO.,LTD.

1. GENERAL INFORMATION.

1.1. Description.

diagonally measured active display area with 240(RGB)×400 resolution. Each pixel is

divided into Red, Green and Blue sub-pixels and dots which are arranged in vertical stripes.

The LCD color is determined with 262,000 colors signal for each pixel.

power, high speed, and high contrast.

viewing angle and low power are critical factors and graphic displays are important.

1.2. Function&Feaures.

Item

Contents

Unit

LCD type

TFT，Normally White, Transmissive,LCD

/

Viewing direction

6 O”Clock

/

Module area (WxH)

45.04(W) x 77.00(H)x2.60mm

mm

Active area(WxH)

38.88(W)×64.80(H)

mm

Number of Dots

240x(RGB)x400Pixels

dots

Pixel Pitch

0.162x0.162

mm

Pixel Arrangement

RGB Vertical Stripes

Driver IC

R61509V(COG)

/

Backligth Type

LED(White，4pcs LED)

/

Interface Type

18 Bits/16Bits/9Bits/8Bits

/

Input volygae

2.8

V
