JH35320480B

VER: 0.1

- 3 -

Issue date: 2013/08/01

JEWEL HILL ELECTRONIC CO.,LTD.

1. General Description

diagonally measured active display area with 320(RGB)×480 resolution. Each pixel is

divided into Red, Green and Blue sub-pixels and dots which are arranged in vertical stripes.

The LCD color is determined with 262,000 colors signal for each pixel.

power, high speed, and high contrast.

viewing angle and low power are critical factors and graphic displays are important.

2. General Features

Item

Display Panel

Remark

Display Mode

Normally White, Transmissive LCD

Viewing Direction

Full View

Input Signals

8/9/16/18Bits RGB

Outside Dimensions

54.64mm(W)*82.94mm(H)*2.0mm(T)

Effective Area

-

Active Area

49.44mm(W)×74.16mm(H)

Number of Pixels

320×RGB×480Pixels

Pixel Pitch

0.1545mm(H)×0.1545mm(W)

Pixel Arrangement

RGB Vertical stripes

Drive IC

R61581B

3. Absolute Maximum Ratings

The following are maximum values which, if exceeded may cause operation or damage to

the unit.

ITEM

Symbol

Min.

Typ.

Max.

Unit

Remark

Power for Circuit Driving

VDD

-0.3

-

3.3

V

Power for Circuit Logic

VCI

-0.3

-

5.0

V

LC Operating Voltage *1)

Vop

-

V

LED Forward Voltage

V

BBBBBBBBB

f

BBBBBBBBB

3.0

3.2

3.4

V

per LED

LED Forward Current

Ir

-

15

-

mA

per LED

LED Luminance

B

BBBBBBBBB

P

BBBBBBBBB

4000

-

-

cd/m

PPPPPPPPP

2

PPPPPPPPPPPPPPPPPPPPPPP

Storage Humidity

H

BBBBBBBBB

ST

BBBBBBBBB

10

-

90

%RH

Storage Temperature

T

BBBBBBBBB

ST

BBBBBBBBB

-30

-

80

℃

Operating Ambient Humidity

H

BBBBBBBBB

OP

BBBBBBBBB

10

-

90

%RH

Operating Ambient temperature

T

BBBBBBBBB

OP

BBBBBBBBB

-20

-

70

℃

At

25±5℃
