BASIC CHARACTERISTICS

Parameter

Condition

Min.

Typ.

Max.

Input Voltage Range

±10%

Operating Frequency

Vin nominal

20kHz

60kHz

100kHz

Output Ripple and Noise

20MHz bandwidth

50mVp-p

100mVp-p

ECO-1

REV.: 0/2015

www.recom-international.com

Refer to Applications Notes

1 Watt

SMD

Single Output

DC/DC Converter

Features

Unregulated

Converters

• SMD Case Style

• Tape and Reel Packaging

• UL-60950-1 Certified

• High Operating Temperature Range from

-40°C to 100°C

• Efficiency up to 76%

• 2kVDC isolation

R1SE/H2

UL-60950-1 Certified

Description

The R1SE/H2 series are 1W unregulated DC/DC converters that are lower cost than equivalent

converters. The benefits of high volume production and semi-automatic assembly allow for a lower

selling price without sacrificing our high quality standards. They are UL certified for safety, offer

reasonable efficiency and still meet the full industrial operating temperature range of -40° to +100°C.

All converters are 100% tested in production and carry our 3-year warranty.

Selection Guide

Part

Input

Output

Output

Efficiency

max. Capacitive

Number

Voltage

Voltage

Current

typ.

Load

(VDC)

(VDC)

(mA)

(%)

(µF)

R1SE-3.305/H2-R

3.3

5

200

75

1000

R1SE-0505/H2-R

5

5

200

75

1000

R1SE-0512/H2-R

5

12

84

76

330

R1SE-0515/H2-R

5

15

66

76

220

R1SE-1205/H2-R

12

5

200

73

1000

R1SE-1505/H2-R

15

5

200

74

1000

3 YEAR

warranty

3

E358085

xx05

xx12

xx15

100

0

20

40

60

80

0

90

80

70

60

50

40

30

20

10

Output Load (%)

Efficiency vs. Load
