SP486E/487EDS/06

SP486E/487E Enhanced Quad RS-485/RS-422 Line Drivers

The circuit model in Figures 6 and 7 represent

the typical ESD testing circuit used for all three

methods. The CS is initially charged with the DC

power supply when the first switch (SW1) is on.

Now that the capacitor is charged, the second

switch (SW2) is on while SW1 switches off. The

voltage stored in the capacitor is then applied

through RS, the current limiting resistor, onto the

device under test (DUT). In ESD tests, the SW2

switch is pulsed so that the device under test

receives a duration of voltage.

For the Human Body Model, the current limiting

resistor (R

S) and the source capacitor (CS) are

1.5kW an 100pF, respectively. For IEC-1000-4-2,

the current limiting resistor (R

S) and the source

capacitor (C

S) are 330W an 150pF, respectively.

The higher C

S value and

lower R

S value in the

IEC1000-4-2 model are more stringent than the

Human Body Model. The larger storage capacitor

injects a higher voltage to the test point when

SW2 is switched on. The lower current limiting

resistor increases the current charge onto the test

point.

DEVICE PIN

HUMAN BODY

IEC1000-4-2

TESTED

MODEL

Air Discharge

Direct Contact

Level

Driver Outputs

+15kV

+8kV

Receiver Inputs

+15kV

+8kV

Table 3. Transceiver ESD Tolerance Levels
