 4 / 4 page
background image
B30
sConnector Mounting Condition
The mounting reference diagram is an anticipated diagram of the condition of mounting to a frame offset 0.15 mm from the card center line.
sPCB mounting pattern
PCB
3.3
+0.1
0
5.5min
(7)
0.7min
Pad
Copper foil portion (Resist layer beyond the pad)
Corner escape portion
(Ø 0.5 through hole)
