D a t a S h e e t
March 11, 2015, MB9B410R-DS706-00026-3v0-E
81
CONFIDENTIAL
・ Multiplexed Bus Access Asynchronous SRAM Mode
(VCC = 2.7V to 5.5V, VSS = 0V, TA = - 40°C to + 85°C)
Parameter
Symbol
Pin name
Conditions
Value
Unit
Min
Max
Multiplexed
address delay time
tALE-CHMADV
MALE
MADATA[15:0]
VCC ≥ 4.5 V
0
10
ns
VCC < 4.5 V
20
Multiplexed
address hold time
tCHMADH
VCC ≥ 4.5 V
MCLK×n+0
MCLK×n+10
ns
VCC < 4.5 V
MCLK×n+0
MCLK×n+20
Note: When the external load capacitance = 30 pF. (m = 0 to 15, n = 1 to 16)
MCLK
MCSX[7:0]
MALE
MOEX
MWEX
MADATA[15:0]
MAD [24:0]
MDQM [1:0]
