MB9BF412R datasheet(102/121 Pages) SPANSION

102 / 121 page

D a t a S h e e t

March 11, 2015, MB9B410R-DS706-00026-3v0-E

CONFIDENTIAL

(12) I

2C timing

(VCC = 2.7V to 5.5V, VSS = 0V, TA = - 40°C to + 85°C)

Parameter

Symbol

Conditions

Standard-mode Fast-mode

Unit Remarks

Min

Max

Min

Max

SCL clock frequency

FSCL

CL = 30 pF,

R = (Vp/IOL)*

100

400 kHz

(Repeated) START condition

hold time

SDA ↓ → SCL ↓

tHDSTA

4.0

0.6

μs

SCLclock L width

tLOW

4.7

1.3

μs

SCLclock H width

tHIGH

4.0

0.6

μs

(Repeated) START setup time

SCL ↑ → SDA ↓

tSUSTA

4.7

0.6

μs

Data hold time

SCL ↓ → SDA ↓ ↑

tHDDAT

3.45*

0.9*

μs

Data setup time

SDA ↓ ↑ → SCL ↑

tSUDAT

250

100

STOP condition setup time

SCL ↑ → SDA ↑

tSUSTO

4.0

0.6

μs

Bus free time between

STOP condition and

START condition

tBUF

4.7

1.3

μs

Noise filter

tSP

8 MHz ≤

tCYCP ≤ 40 MHz

2 tCYCP*

tCYCP*

40 MHz <

tCYCP ≤ 60 MHz

3 tCYCP*

tCYCP*

60 MHz <

tCYCP ≤ 72 MHz

4 tCYCP*

tCYCP*

*1: R and C represent the pull-up resistance and load capacitance of the SCL and SDA lines, respectively.

Vp indicates the power supply voltage of the pull-up resistance and IOL indicates VOL guaranteed current.

*2: The maximum tHDDAT must satisfy that it doesn't extend at least L period (tLOW) of device's SCL signal.

*3: Fast-mode I

2C bus device can be used on Standard-mode I2C bus system as long as the device satisfies the

requirement of tSUDAT ≥ 250 ns.

*4: tCYCP is the APB bus clock cycle time.

About the APB bus number that I2C is connected to, see "■ Block Diagram" in this data sheet.

To use Standard-mode, set the APB bus clock at 2 MHz or more.

To use Fast-mode, set the APB bus clock at 8 MHz or more.

*5: The number of the steps of the noise filter can be changed by register settings.

Change the number of the noise filter steps according to APB2 bus clock frequency.

SDA

SCL
