Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.

Please note that the contents may change without any prior notice due to reasons such as upgrading.

Inductors for Power Circuits

Wound Ferrite

FEATURES

High-current SMD inductor.

Low-profile design.

High output processing capacity: Minimal copper loss

High saturation current and low DC resistance.

High operating frequency: Up to 2MHz

APPLICATION

Personal computers, servers (Voltage Regulator Modules, etc.)

Amusement equipment, AV equipment, etc.

PART NUMBER CONSTRUCTION

OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT

Product compatible with RoHS directive

Halogen-free

Compatible with lead-free solders

Overview of VLB10050 Type

VLB

10050

H

T

-

R12

M

Series name

L×W×H Dimensions

characteristics

Packaging style

Inductance

Inductance

tolerance

（mm max.）

(nH)

10050

10.2×7.0×5.0

T

Taping

R12

120

M

±20%

R30

300

Type

Temperature range

Package quantity

Individual weight

Operating

（°C）

Storage

（°C）

(pieces/reel)

（g）

VLB10050

–40 to +125

–40 to +125

500

1.40

RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://product.tdk.com/en/environment/rohs/

Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm.
