background image
INCHANGE Semiconductor
isc RF Product Specification
isc website：www.iscsemi.cn
2
isc Silicon NPN RF Transistor
2SC4807
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
MAX
UNIT
V(BR)CBO
Collector-Base Breakdown Voltage
IC= 10μA; IE= 0
20
V
ICBO
Collector Cutoff Current
VCB= 15V; IE= 0
1
μ
A
ICEO
Collector Cutoff Current
VCE= 15V; RBE= ∞
1
μ
A
IEBO
Emitter Cutoff Current
VEB= 2V; IC= 0
10
μ
A
hFE
DC Current Gain
IC= 100mA ; VCE= 5V
50
250
fT
Current-Gain—Bandwidth Product
IC= 100mA ; VCE= 5V
3.0
4.4
GHz
COB
Output Capacitance
IE= 0 ; VCB= 5V; f= 1.0MHz
2.8
4.0
pF
PG
Power Gain
IC= 100mA ; VCE= 5V; f= 900MHz
5.0
7.0
dB
NF
Noise Figure
IC= 20mA ; VCE= 5V; f= 900MHz
2.5
4.0
dB
