Product Search Data Sheet

SFSCE10M7WF05-R0

Appearance & Shape

Applications

Other Usage

Communication Equipment

Packaging Information

Packaging

Specifications

Minimum

Order Quantity

-R0

180mm Embossed Tape

1500

Features

SFSCE series are chip surface mount filters available for 3dB

bandwidth at 700kHz to 1.3MHz (more than twice width compared

with current types). They have 1.0mm max. thickness and small

mounting area (4.5x3.8mm).

Features

1. The filters are mountable by automatic placers.

2. They are slim, at only 1.0mm max. thickness, and have a small

mounting area (4.5x3.8mm) enabling flexible PCB design.

3. Available lead (Pb) free solder reflow.

4. Operating temperature range: -20 to +80 (degrees C), Storage

temperature range: -40 to +85 (degrees C)

1 of 3

Atten ti o n

1.T his datasheet is downloaded from the website of Murata Manufacturing Co., Ltd. T herefore, it’s specifications are subject to change or our products in it may be discontinued

without advance notice. Please check with our sales representatives or product engineers before ordering.

2.T his datasheet has only typical specifications because there is no space for detailed specifications.

T herefore, please review our product specifications or consult the approval sheet for product specifications before ordering.

URL : http://www.murata.com/

Last

：

updated 2016/06/24
