INNOLINE

DC/DC-Converter

R-78Txx-1.0

Series

R-78Txx-1.0/FC

23

25

1 23

2.2

5.08

2.54

2.2

6.72

8 max.

2.2

10.16

Pin Connections

Pin #

1

+Vin

2

GND

3

+Vout

Top

Bottom View

Package Style and Pinning (mm)

Tolerance ±0.5mm unless otherwise specified

10.16

2.54

1.20± 0.1

Bottom View

Recommended Footprint

I-36

www.recom-power.com

REV: 1/2016
