DAC8165

www.ti.com

SBAS409B

– FEBRUARY 2008 – REVISED MARCH 2011

DAC Output Noise Density

Full-Scale Range (FSR)

Output

noise

density

defined

Full-scale range (FSR) is the difference between the

internally-generated random noise. Random noise is

maximum and minimum analog output values that the

characterized as a spectral density (nV/

√Hz). It is

DAC is specified to provide; typically, the maximum

measured by loading the DAC to midscale and

and minimum values are also specified. For an n-bit

measuring noise at the output.

DAC, these values are usually given as the values

matching with code 0 and 2n.

DAC Output Noise

DAC output noise is defined as any voltage deviation

of DAC output from the desired value (within a

particular frequency band). It is measured with a DAC

channel kept at midscale while filtering the output

voltage within a band of 0.1Hz to 10Hz and

measuring its amplitude peaks. It is expressed in

terms of peak-to-peak voltage (Vpp).

Submit Documentation Feedback

Product Folder Link(s): DAC8165
