30
4256B–USB–03/06
AT89C5132
Appendix A
Table 17. Summary of Frames from Host
Command Identifier
data[0]
data[1]
data[2]
data[3]
data[4]
Description
Id_prog_start
01h
00h
start_address
end_address
Init Flash programming
Id_display_data
03h
00h
start_address
end_address
Display Flash Data
01h
Blank Check in Flash
Id_write_command
04h
00h
00h
Erase block0 (0K to 8K)
20h
Erase block1 (8K to 16K)
40h
Erase block2 (16K to 32K)
80h
Erase block3 (32K to 64K)
FFh
Full Chip Erase (bits at FFh)
01h
00h
Value
Write value in BSB
01h
Write value in SBV
05h
Write value in SSB
06h
Write value in EB
02h
00h
Value
Write value in Fuse (HSB)
03h
00h
Hardware reset
01h
address
LJMP address
Id_read_command
05h
00h
00h
Read Bootloader Version
01h
Read Device boot ID1
02h
Read Device boot ID2
01h
00h
Read BSB
01h
Read SBV
05h
Read SSB
06h
Read EB
30h
Read Manufacturer Code
31h
Read Family Code
60h
Read Product Name
61h
Read Product Revision
02h
00h
Read HWB
