1 / 2 page

S2MB

S2KB

S2JB

S2GB

S2DB

S2BB

S2AB

Case: SMB(DO-214AA)Molded Plastic

S2AB - S2MB

VOLTAGE RANGE: 50 - 1000V

CURRENT: 2.0 A

Features

@TA = 25°C unless otherwise specified

Glass Passivated Die Construction

Low Forward Voltage Drop and High Current

Capability

Ideally Suited for Automated Assembly

Single phase, half wave, 60Hz, resistive or inductive load. For capacitive load, derate current by 20%.

Mechanical Data

Case Material - UL Flammability Rating

Classification 94V-0

Terminals: Solder Plated Terminal -

Solderable per MIL-STD-202, Method 208

Polarity: Cathode Band or Cathode Notch

Maximum Ratings and Electrical Characteristics

Weight: 0.093 grams (approx.)

1 of 2

www.sunmate.tw

16

°C/W

30

pF

200

1.1

V

60

A

2.0

A

= 2.0A

Notes:

1. Measured at 1.0 MHz and applied reverse voltage of 4.0V DC.

2. Thermal Resistance Junction to Terminal, unit mounted on PC board with 5.0 mm2 (0.013 mm thick) copper pads as heat sink.

Characteristic

Symbol

Unit

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

VRRM

VRWM

VR

50

100

200

400

600

800

1000

V

RMS Reverse Voltage

VR(RMS)

35

70

140

280

420

560

700

V

Average Rectified Output Current

@ TT = 100°C

I(AV)

Non-Repetitive Peak Forward Surge Current 8.3ms

single half sine-wave superimposed on rated load

(JEDEC Method)

IFSM

Forward Voltage

@ IF

VFM

Peak Reverse Current

@TA = 25°C

at Rated DC Blocking Voltage

@TA = 125°C

IRM

5.0

µA

Typical Total Capacitance (Note 1)

CT

Typical Thermal Resistance, Junction to Terminal

(Note 2)

RqJT

Operating and Storage Temperature Range

Tj, TSTG

-65 to +150

°C

!

SMB(DO-214AA)

Dim

Min

Max

A

B

C

1.91

2.21

D

0.15

0.31

E

5.00

5.59

G

0.10

0.20

H

0.76

1.52

J

2.00

2.62

All Dimensions in mm

A

B

C

D

G

H

E

J

3.30

3.94

4.06

4.70

A

B

C

D

G

H

E

J

SURFACE MOUNT SILICON RECTIFIER DIODES
