HRK Series

Description

• #14 AWG copper wire leads

• 8" (203mm) leads

• Three springs furnished to accept different fuse lengths

• Flammability rating: UL 94V0

Ordering

• Specify packaging, product, and option code

© 2009 Cooper Bussmann

St. Louis, MO 63178

www.cooperbussmann.com

0909

BU-SB09868

Page 1 of 1

Data Sheet 2111

The only controlled copy of this Data Sheet is the electronic read-only version located on the Cooper Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin is

intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Cooper Bussmann reserves the right, without notice, to change

design or construction of any products and to discontinue or limit distribution of any products. Cooper Bussmann also reserves the right to change or update, without notice, any technical information con-

tained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.

Life Support Policy: Cooper Bussmann does not authorize the use of any of its products for use in life support devices or systems without the express written approval of an officer of the Company. Life sup-

port systems are devices which support or sustain life, and whose failure to perform, when properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result

in significant injury to the user.

Specifications

Product

Voltage

Current

Code

Rating

Rating

HRK-R

32V

15A

Dimensions – in (mm)

Drawing Not to Scale

Packaging Code

Packaging Code Prefix

Description

Blank

10 fuse holders packed into a carton

BK

100 fuse holders packed into a carton
