PACKAGE OPTION ADDENDUM

www.ti.com

12-Oct-2016

Addendum-Page 1

PACKAGING INFORMATION

Orderable Device

Status

(1)

Package Type Package

Drawing

Pins Package

Qty

Eco Plan

(2)

Lead/Ball Finish

(6)

MSL Peak Temp

(3)

Op Temp (°C)

Device Marking

(4/5)

Samples

UCD3138ARGCR

ACTIVE

VQFN

RGC

2000

Green (RoHS

& no Sb/Br)

CU NIPDAU

Level-2-260C-1 YEAR

-40 to 125

UCD3138A

UCD3138ARGCT

ACTIVE

VQFN

RGC

250

Green (RoHS

& no Sb/Br)

CU NIPDAU

Level-2-260C-1 YEAR

-40 to 125

UCD3138A

UCD3138ARJAR

PREVIEW

VQFN

RJA

3000

Green (RoHS

& no Sb/Br)

CU NIPDAUAG

Level-2-260C-1 YEAR

-40 to 125

UCD3138A

UCD3138ARJAT

PREVIEW

VQFN

RJA

250

Green (RoHS

& no Sb/Br)

CU NIPDAUAG

Level-2-260C-1 YEAR

-40 to 125

UCD3138A

UCD3138ARMHR

ACTIVE

WQFN

RMH

2000

Green (RoHS

& no Sb/Br)

CU NIPDAU

Level-2-260C-1 YEAR

-40 to 125

UCD3138A

UCD3138ARMHT

ACTIVE

WQFN

RMH

250

Green (RoHS

& no Sb/Br)

CU NIPDAU

Level-2-260C-1 YEAR

-40 to 125

UCD3138A

(1) The marketing status values are defined as follows:

ACTIVE: Product device recommended for new designs.

LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.

NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in a new design.

PREVIEW: Device has been announced but is not in production. Samples may or may not be available.

OBSOLETE: TI has discontinued the production of the device.

(2) Eco Plan - The planned eco-friendly classification: Pb-Free (RoHS), Pb-Free (RoHS Exempt), or Green (RoHS & no Sb/Br) - please check http://www.ti.com/productcontent for the latest availability

information and additional product content details.

TBD: The Pb-Free/Green conversion plan has not been defined.

Pb-Free (RoHS): TI's terms "Lead-Free" or "Pb-Free" mean semiconductor products that are compatible with the current RoHS requirements for all 6 substances, including the requirement that

lead not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, TI Pb-Free products are suitable for use in specified lead-free processes.

Pb-Free (RoHS Exempt): This component has a RoHS exemption for either 1) lead-based flip-chip solder bumps used between the die and package, or 2) lead-based die adhesive used between

the die and leadframe. The component is otherwise considered Pb-Free (RoHS compatible) as defined above.

Green (RoHS & no Sb/Br): TI defines "Green" to mean Pb-Free (RoHS compatible), and free of Bromine (Br) and Antimony (Sb) based flame retardants (Br or Sb do not exceed 0.1% by weight

in homogeneous material)

(3) MSL, Peak Temp. - The Moisture Sensitivity Level rating according to the JEDEC industry standard classifications, and peak solder temperature.

(4) There may be additional marking, which relates to the logo, the lot trace code information, or the environmental category on the device.

(5) Multiple Device Markings will be inside parentheses. Only one Device Marking contained in parentheses and separated by a "~" will appear on a device. If a line is indented then it is a continuation

of the previous line and the two combined represent the entire Device Marking for that device.
