3

Part No.

U.FL-R-SMT(01)

U.FL-R-SMT(10)

CL No.

331-0471-0-01

331-0471-0-10

Packaging

Bag packaging (100 pieces/bag)

Reel packaging (2500 pieces/reel)

Weight (mg)

15.7/unit

sReceptacles

Note 1: Receptacles of (01) specification are sold by the

bag with 100 pieces per bag.

Please order in pack units.

Note 2: Receptacles of (10) specification are sold by the

reel (which contains 2,500 pieces).

Please order in reel units.

Note 3: This area may be covered by insulating material.

qPackaging Specifications

Embossed Carrier Tape Dimensions

Reel Dimensions

GND

GND

GND

GND

Cut Out Prohibition Area

Recommended PCB mounting pattern

SIG

SIG

Ø2

3

2.6

0.6

1±0.05

4±0.05

1.9±0.05

8±0.1

2±0.1

4±0.1

0.3

1.6

Center contact

Unreeling direction

1.8

14

Ø13

Ø21

The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.

All non-RoHS products have been discontinued, or will be discontinued soon. Please check the products status on the Hirose website RoHS search at www.hirose-connectors.com, or contact your Hirose sales representative.
