QUICK REFERENCE DATA

3.1 Absolute Maximum Ratings

Operation of the device beyond these conditions is not guaranteed.

Sustained exposure to these limits will adversely affect device reliability

Table 1. Absolute Maximum Ratings

3.2 Operating Ranges

Operating ranges define the limits for functional operation and parametric characteristics of the device.

Functionality outside these limits is not implied.

Table 2. Operating Ranges

3.3 I/O specifications

Depending on the interface, the I/O voltage is typical 1.8V (interface to the flash memory) or typical 3.3V

(all the other interfaces). These I/Os comply to the EIA/JEDEC standard JESD8-B.

3.3.1 Specifications for 3.3V I/Os

Note 1 : X is the source/sink current under worst case conditions according to the drive capability. (See table 8, pad information for value of X).

Symbol

Conditions

Min

Max

Unit

Supply voltage core

2.5

V

Supply voltage I/O

4

V

input voltage on any digital pin

V

Operating ambient temperature

-40

+85

°C

Storage temperature

-65

+150

°C

Lead temperature < 10s

+240

°C

Symbol

Conditions

Min

Typ

Max

Unit

Supply voltage digital core and emi pads

1.55

1.8

1.95

V

Supply voltage digital IO

2.7

3.3

3.6

V

Operating ambient temperature

-40

+85

°C

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

Low level input voltage

0.8

V

High level input voltage

2

V

Schmitt trigger hysteresis

0.4

V

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

Note

Low level output voltage

0.15

V

1

V

1
