Bottom View

Top View

16.95max.

0.25

11.40

0.60

0.50±0.05

15.24

4.10

2.54 x 11

14.40

32.35

16.10

12

11

10

9

8

2

1

24 23

17 16 15 14 13

Single & Dual Output

24 23

17 16 15 14 13

12

11

10

9

8

2

1

RECOM

RV-0505D/R6.4

****

2.2

2.54

2.54

1.0ø+0.15/–0

ECONOLINE

DC/DC-Converter

Package Style and Pinning (mm)

24 PIN DIP Miniature Package Style

Pin Connections

Pin #

Single

1

+Vin

2

-Vin

8, 9, 11, 14

NC

10, 15

-Vout

12 & 13

+Vout

16, 17, 23, 24

NC

NC = No Connection

Pin Connections

Pin #

Dual

1

+Vin

2

-Vin

8, 17

-Vout

9, 11, 14,16, 23, 24

NC

10 & 15

Com

12, 13

+Vout

NC = No Connection

Recommended Footprint Details

XX.X ± 0.5 mm

XX.XX ± 0.25 mm

RV/R

Series

The product information and specifications are subject to change without prior notice. RECOM products are not authorized for use in safety-critical applications (such as life support) without RECOM’s explicit

written consent. A safety-critical application is defined as an application where a failure of a RECOM product may reasonably be expected to endanger or cause loss of life, inflict bodily harm or damage property. The buyer

shall indemnify and hold harmless RECOM, its affiliated companies and its representatives against any damage claims in connection with the unauthorized use of RECOM products in such safety-critical applications.

REV: 1/2015

www.recom-power.com

E-116
