1 / 4 page

FEATURES

Reduced case size - High voltage – Low Leakage – low dissipation

Factor – JIS 2365 Compliant

APPLICATIONS

Emergency lights – Signal lights

Operating Temperature Range

-20°C to +55°C

Capacitance Tolerance

-10 to+20% at 120 Hz, 25°C

WVDC

300

310

330

360

Surge voltage

SVDC

320

335

350

390

Dissipation Factor

120 Hz, 25°C

tan

δ

0.06

time

5 Minutes

Leakage current

@25°C, Rated WVDC applied

1*C

5000 flashes at rated voltage applied at 5~35°C repeating every 30

seconds thru a Xe flash tube having a discharge resistance of 0.7~1.0

Ω

Capacitance change

<10% of initial measured value

Dissipation factor

<150% of maximum specified value

Charge/discharge

Leakage current

<150% of maximum specified value

500 hours at 55°C with no voltage applied

Capacitance change

<10% initial measured value

Dissipation factor

<150% of maximum specified value

Shelf Life

Leakage current

<150% of maximum specified value

D1=D+0.3mm

L1=L+0.5mm

S1=D+0.5mm

D

9.2

9.5

10

10.3

10.6

11

12

12.5

13

13.5

14

14.5

16

18

20

d

0.6

0.8

S

5.0

7.5
