607MDCL700KFK datasheet(1/4 Pages) ILLINOISCAPACITOR

부품명	607MDCL700KFK

상세설명	Male/female lead styles - High voltage/current ??Low ESR

PDF	4 Pages

Scroll/Zoom	100%

제조업체	ILLINOISCAPACITOR [Illinois Capacitor, Inc.]

홈페이지	http://www.illinoiscapacitor.com

Logo

1 / 4 page

FEATURES

Male/female lead styles - High voltage/current – Low ESR

APPLICATIONS

Induction heaters – DC link – AC/DC motor controls – Power

inverters

Operating Temperature

Range

-40°C to +85°C

Storage Temperature Range

-40°C to +85°C

Capacitance Tolerance

+10% at 1 kHz, 25°C

Surge Voltage

WVDC

450

700

900

1100

1500

2000

SVDC

1.5*WVDC

Dissipation Factor

Max at 100 Hz, 25°C

.25%

Insulation Resistance

@20°C (<70% RH)for 1

minute at 100VDC applied

10000 Megohmxmicrofarads(seconds)

Dielectric Strength

Terminal to Terminal

Terminal to Case

150% of VDC applied for 60

Seconds and 25°C

3 KVAC (50/60 Hz) applied

for 60 seconds at 25°C

Life expectancy

Up to 100000 hours @70°C

Capacitance Change

<15% of initially measured value

Long term Stability

<1% after 2 years at standard environmental conditions

Reliability

300 FIT

Construction

Metallized polypropylene film and internal series

connections

Casing

Metal can with epoxy fill (UL94V-0)

MAXIMUM ALTITUDE

3500 m

Lead terminations

Lead free tinned Brass leads (RoHS compliant)
