AB08X5 Real-Time Clock Family

Date of Issue: October 16, 2014

3.0 x 3.0 mm

Page 19 of 33

Abracon Drawing #453567

Revision: C

Figure 12 shows the typical VBAT power state operating current vs. temperature in RC mode.

Figure 12. Typical VBAT Current vs. Temperature in RC Mode

Figure 13 shows the typical VBAT power state operating current vs. temperature in RC Autocalibration

mode.

Figure 13. Typical VBAT Current vs. Temperature in RC Autocalibration Mode

5

15

25

35

45

55

65

75

‐40

‐30

‐20

‐10

0

10

20

304050607080

Temperature  (°C)

VBAT = 1.8V

VBAT = 3.0V

5

10

15

20

25

30

35

40

45

50

55

‐40

‐30

‐20

‐10

0

10203040

50

6070

Temperature (°C)

VBAT = 1.8V

VBAT = 3.0V
