Product Dimensions

DIMENSIONS:

MM

(INCHES)

Model

A

B

C

D

E

F

Physical Characteristics

Max.

Max.

Nom.

Tol. ±

Min.

Max.

Nom.

Style

Material

PRCP-RHT070

6.86

(0.27)

10.8

(0.425)

5.1

(0.201)

0.7

(0.028)

7.6

(0.30)

3.0

(0.12)

0.51

(0.020)

1

Sn/CuFe

PRCP-RHT200

9.4

(0.37)

14.0

(0.55)

5.1

(0.201)

0.7

(0.028)

7.6

(0.30)

3.0

(0.12)

0.51

(0.020)

3

Sn/Cu

PRCP-RHT450

10.4

(0.41)

15.6

(0.61)

5.1

(0.201)

0.7

(0.028)

7.6

(0.30)

3.0

(0.12)

0.81

(0.032)

2

Sn/Cu

PRCP-RHT650

12.7

(0.50)

22.2

(0.88)

5.1

(0.201)

0.7

(0.028)

7.6

(0.30)

3.0

(0.12)

0.81

(0.032)

2

Sn/Cu

PRCP-RHT750

14.0

(0.55)

23.5

(0.93)

5.1

(0.201)

0.7

(0.028)

7.6

(0.30)

3.0

(0.12)

0.81

(0.032)

2

Sn/Cu

PRCP-RHT1300

23.5

(0.925)

28.7

(1.17)

10.2

(0.402)

0.7

(0.028)

7.6

(0.30)

3.6

(0.14)

1.0

(0.040)

2

Sn/Cu

Packaging:

BULK:

500 pcs. per bag

TAPE & REEL: PRCP-RHT070 ~ PRCP-RHT200 = 3000 pcs. per reel; PRCP-RHT450 ~ PRCP-RHT650 = 1500 pcs. per reel;

PRCP-RHT750 ~ PRCP-RHT1300 = 1000 pcs. per reel

Typical Time to Trip at 23 °C

Typical Part Marking

Represents total content. Layout may vary.

0.51 (24AWG)

0.81 (20AWG)

1.0 (18AWG)

Applications

Protection of automotive circuitry including engine control modules

Overcurrent surge protection of electronic equipment required to operate at high operating temperature ranges

t

Resettable fault protection of general electronic equipment

A

E

B

D

C

E

Style 2

B

D

A

C

F

Style 1

F

F

A

E

B

D

C

Style 3

RH750

4180S

MANUFACTURER'S

MARK

PART

IDENTIFICATION

COUNTRY OF

MANUFACTURE

(S = CHINA)

DATE CODE

(FIRST DIGIT =

LAST DIGIT OF YEAR;

NEXT THREE DIGITS =

DAY OF YEAR)

EXAMPLE: 4180 = 2004 DAY 180

0.01

0.1

1

10

100

0

0

1

0

1

1

Fault Current (Amps)

PRCP-RHT070 PRCP-RHT200

PRCP-RHT450

PRCP-RHT1300

PRCP-RHT650

PRCP-RHT750

The Time to Trip curves represent

typical performance of a device in

a simulated application environment.

customer applications may differ

from these values due to the

influence of other variables.

Actual performance in specific

Specifications are subject to change without notice.

Customers should verify actual device performance in their specific applications.

The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
