1–1

Information Storage Devices, Inc.

1

®

FEATURES

•

Easy-to-use single-chip voice Record/Play-

back solution

•

High-quality, natural voice/audio

reproduction

•

Manual switch or microcontroller compatible

–

Playback can be edge- or level-

activated

•

Single-chip durations of 16 and 20 seconds

•

Directly cascadable for longer durations

•

Power-down mode

–1

µA standby current (typical)

•

Zero-power message storage

–

Eliminates battery backup circuits

•

Fully addressable to handle multiple

messages

•

100-year message retention (typical)

•

100,000 record cycles (typical)

•

On-chip clock source

•

No algorithm development required

•

Single +5 volt supply

•

Available in die form, DIP, and SOIC

packaging

•

Industrial temperature (-40

°C to +85°C)

version available

ISD1000A Series

Single-Chip Voice Record/Playback Devices

16- and 20-Second Durations

ISD1000A SERIES SUMMARY

Part

Number

Duration

(Seconds)

Input Sample

Rate (KHz)

Typical Filter

Pass Band

(KHz)

ISD1016A

16

8

3.4

ISD1020A

20

6.4

2.7

06.DataBook_1000A Dsht Page 1 Friday, September 27, 1996 10:44 AM
