Rev 1.0
6/13
vicorpower.com
Applications Engineering: 800 927.9474
Page 14
Cool-Power® Series
Evaluation Board
High Density Isolated DC-DC Converter
OUT+
OUT
OUT–
IN–
IN+
ENABLE
TRIM_DN
TRIM_UP
F1
L1
C5
INP
CY1
CY2 OUTP
YP
INN
CY3
CY4
OUTN
YN
OPT1 OPT2
C7
R1
R4
R3
R2
C6
PI31
-
EVAL1
0.250”
0.150”
1.55”
0.750”
0.150”
0.335”
0.335”
3.100”
2.430”
0.250”
3.100”
2.600”
0.750”
Figure 13.
Mechanical Drawing
Ordering Information
The PI31xx Customer Evaluation Boards are specified by adding the suffix “-EVAL1” to
the base PI31xx-xx model number.
Go to http://www.vicorpower.com/cms/home/company/contact-us for
ordering information.
