Product Dimensions

DIMENSIONS:

MM

(INCHES)

Model

A

B

C

D

E

F

Physical Characteristics

Max.

Max.

Nom.

Tol. ±

Min.

Max.

Nom.

Style

Material

MF-RHT050

7.40

(0.291)

12.7

(0.500)

5.1

(0.201)

0.7

(0.028)

7.6

(0.30)

3.0

(0.12)

0.51

(0.020)

3

Sn/CuFe

MF-RHT070

6.86

(0.27)

10.8

(0.425)

5.1

(0.201)

0.7

(0.028)

7.6

(0.30)

3.0

(0.12)

0.51

(0.020)

1

Sn/CuFe

MF-RHT200

9.4

(0.37)

14.0

(0.55)

5.1

(0.201)

0.7

(0.028)

7.6

(0.30)

3.0

(0.12)

0.51

(0.020)

3

Sn/Cu

MF-RHT450

10.4

(0.41)

15.6

(0.61)

5.1

(0.201)

0.7

(0.028)

7.6

(0.30)

3.0

(0.12)

0.81

(0.032)

2

Sn/Cu

MF-RHT650

12.7

(0.50)

22.2

(0.88)

5.1

(0.201)

0.7

(0.028)

7.6

(0.30)

3.0

(0.12)

0.81

(0.032)

2

Sn/Cu

MF-RHT750

14.0

(0.55)

23.5

(0.93)

5.1

(0.201)

0.7

(0.028)

7.6

(0.30)

3.0

(0.12)

0.81

(0.032)

2

Sn/Cu

MF-RHT1300

23.5

(0.925)

28.7

(1.17)

10.2

(0.402)

0.7

(0.028)

7.6

(0.30)

3.6

(0.14)

1.0

(0.040)

2

Sn/Cu

Packaging:

BULK:

500 pcs. per bag

TAPE & REEL: MF-RHT050 ~ MF-RHT200 = 3000 pcs. per reel; MF-RHT450 ~ MF-RHT650 = 1500 pcs. per reel;

MF-RHT750 ~ MF-RHT1300 = 1000 pcs. per reel

AMMO-PACK: MF-RHT050 ~ MF-RHT200 = 2000 pcs. per pack; MF-RHT450 ~ MF-RHT750 = 1000 pcs. per pack;

MF-RHT1300 = 500 pcs. per pack

MF-RHT SERIES, REV. J, 09/16

Typical Time to Trip at 23 ˚C

Typical Part Marking

Represents total content. Layout may vary.

0.51 (24AWG)

0.81 (20AWG)

1.0 (18AWG)

Applications

n

Protectionofautomotivecircuitryincludingenginecontrolmodules

n

Overcurrentsurgeprotectionofelectronicequipmentrequiredtooperateathighoperatingtemperatureranges

n

Resettablefaultprotectionofgeneralelectronicequipment

A

E

B

D

C

E

Style 2

B

D

A

CF

Style 1

F

F

A

E

B

D

C

Style

RH750

4180S

MANUFACTURER'S

TRADEMARK

PART

IDENTIFICATION

COUNTRYOF

MANUFACTURE

(S=CHINA)

DATECODE

(FIRSTDIGIT=

LASTDIGITOFYEAR;

NEXTTHREEDIGITS=

DAYOFYEAR)

EXAMPLE:4180=2004DAY180

0.01

0.1

1

10

100

110

100

Fault Current (Amps)

MF-RHT070

MF-RHT200

MF-RHT450

MF-RHT1300

MF-RHT650

MF-RHT750

The Time to Trip curves represent

typical performance of a device in

a simulated application environment.

Actual performance in specific

customer applications may differ

from these values due to the

influence of other variables.

Also available

with kinked

and straight

leads in place

of standard

leads (see

How to Order).
