TCM811/TCM812

DS21615B-page 8

 2002 Microchip Technology Inc.

4.2

Package Dimensions

.055 (1.40)

.047 (1.20)

.080 (2.03)

.070 (1.78)

.079 (2.00)

.071 (1.80)

.098 (2.50)

.083 (2.10)

.040 (1.02)

.031 (0.79)

.004 (0.10)

.001 (0.02)

.120 (3.05)

.105 (2.67)

.037 (0.94)

.030 (0.77)

.021 (0.54)

.015 (0.38)

.006 (0.15)

.004 (0.09)

.010 (0.25)

.005 (0.13)

8 MAX.

Component Taping Orientation for 4-Pin SOT-143 Devices

PIN 1

Device

Marking

User Direction of Feed

Standard Reel Component Orientation

for TR Suffix Device

(Mark Right Side Up)

W

P

Carrier Tape, Number of Components Per Reel and Reel Size:

Package

Carrier Width (W)

Pitch (P)

Part Per Full Reel

Reel Size

4-Pin SOT-143

8 mm

4 mm

3000

7 in.
