MAXM17543 데이터시트(PDF) 13 Page - Maxim Integrated Products |
|
|
|||||||||||||||||||||||||||||
MAXM17543 데이터시트(HTML) 13 Page - Maxim Integrated Products |
|
|
13 / 18 page  Table 1. Selection Component Values VIN (V) VOUT (V) CIN COUT RU (kΩ) RB (kΩ) fSW (kHz) RT (kΩ) 4.5 to 15 0.9 3 x 2.2µF 1206 100V 2 x 100µF 1210 4V 35.7 Open 300 68.1 4.5 to 15 1 3 x 2.2µF 1206 100V 2 x 100µF 1210 4V 35.7 324 300 68.1 4.5 to 15 1.2 3 x 2.2µF 1206 100V 1 x 100µF 1 x 47µF 1210 4V 41.2 124 350 57.6 4.5 to 15 1.5 3 x 2.2µF 1206 100V 1 x 100µF 1 x 47µF 1210 4V 57.6 86.6 350 57.6 4.5 to 15 1.8 3 x 2.2µF 1206 100V 1 x 100µF 1210 4V 61.9 61.9 350 57.6 4.5 to 15 2.5 3 x 2.2µF 1206 100V 1 x 100µF 1210 4V 53.6 30.1 400 49.9 4.5 to 15 3.3 2 x 2.2µF 1206 100V 1 x 47µF 1210 10V 130 48.7 500 Open 6.5 to 15 5 2 x 2.2µF 1206 100V 1 x 22µF 1210 10V 191 42.2 740 26.7 11 to 15 8 2 x 2.2µF 1206 100V 1 x 10µF 1210 16V 309 39.2 1200 15.8 4.5 to 28 0.9 3 x 2.2µF 1206 100V 3 x 100µF 1210 4V 35.7 Open 214 95.3 4.5 to 28 1 3 x 2.2µF 1206 100V 3 x 100µF 1210 4V 35.7 324 238 86.6 4.5 to 28 1.2 3 x 2.2µF 1206 100V 2 x 100µF 1210 4V 41.2 124 285 71.5 4.5 to 28 1.5 3 x 2.2µF 1206 100V 1 x 100µF 1 x 47µF 1210 4V 57.6 86.6 350 57.6 4.5 to 28 1.8 3 x 2.2µF 1206 100V 1 x 100µF 1210 4V 61.9 61.9 350 57.6 4.5 to 28 2.5 3 x 2.2µF 1206 100V 1 x 100µF 1210 4V 53.6 30.1 400 49.9 4.5 to 28 3.3 2 x 2.2µF 1206 100V 1 x 47µF 1210 10V 130 48.7 500 Open 6.5 to 28 5 2 x 2.2µF 1206 100V 1 x 22µF 1210 10V 191 42.2 740 26.7 11 to 28 8 2 x 2.2µF 1206 100V 1 x 10µF 1210 16V 309 39.2 1200 15.8 18.5 to 28 12 2 x 2.2µF 1206 100V 1 x 4.7µF 1210 16V 464 37.4 1800 10.0 4.5 to 42 1.2 3 x 2.2µF 1206 100V 2 x 100µF 1 x 47µF 1210 4V 41.2 124 200 100.00 4.5 to 42 1.5 3 x 2.2µF 1206 100V 1 x 100µF 1 x 47µF 1210 4V 57.6 86.6 250 82.5 4.5 to 42 1.8 3 x 2.2µF 1206 100V 1 x 100µF 1 x 47µF 1210 4V 61.9 61.9 300 68.1 4.5 to 42 2.5 3 x 2.2µF 1206 100V 1 x 100µF 1210 4V 53.6 30.1 400 49.90 4.5 to 42 3.3 2 x 2.2µF 1206 100V 1 x 47µF 1210 10V 130 48.7 500 Open 6.5 to 42 5 2 x 2.2µF 1206 100V 1 x 22µF 1210 10V 191 42.2 740 26.7 11 to 42 8 2 x 2.2µF 1206 100V 1 x 10µF 1210 16V 309 39.2 1200 15.8 18.5 to 42 12 2 x 2.2µF 1206 100V 1 x 4.7µF 1210 16V 464 37.4 1800 10.00 www.maximintegrated.com Maxim Integrated │ 13 MAXM17543 4.5V to 42V, 2.5A High-Efficiency, DC-DC Step-Down Power Module with Integrated Inductor |
|
|
