background image
2016-01-25
4
Version 1.5
CW CBLPM1.S1
Characteristics (TS = 25 °C; IF = 1000 mA)
Kennwerte
Parameter
Symbol
Values
Unit
Bezeichnung
Symbol
Werte
Einheit
Chromaticity coordinates acc. to CIE 1931 4) page 23
Farbkoordinaten nach CIE 1931 4) Seite 23
(typ.)
(typ.)
Cx
Cy
0.33
0.34
-
-
Viewing angle at 50 % IV
Abstrahlwinkel bei 50 % IV
(typ.)
2ϕ
120
°
Forward voltage
5) page 23
Durchlassspannung 5) Seite 23
(min.)
(typ.)
(max.)
VF
VF
V
F
2.95
3.05
3.70
V
V
V
Reverse current
Sperrstrom
I
R
not designed for
reverse operation
"Electrical" thermal resistance junction / solder point
6) page 23
"Elektrischer" Wärmewiderstand Sperrschicht /
Lötpad 6) Seite 23
(acc. to JEDEC 51-14 and 51-51, with efficiency
η
e = 27 %)
(typ.)
Rth JS el
8.0
K/W
