TAPE AND REEL SPECIFICATIONS
COMPONENT ROTATION
TYPICAL
COMPONENT CAVITY
CENTER LINE
TYPICAL
COMPONENT
CENTER LINE
10° MAXIMUM
COMPONENT
ROTATION
SMTR AMS DRW# 040203
REEL DIMENSIONS
A
D
C
B
W
2
(MEASURED AT HUB)
W
1
(MEASURED AT HUB)
SMTR AMS DRW# 040204
TAPE SIZE
A
B MIN
C
D MIN
W 1
W2
12mm
330
+0.25
–4.0
(12.992) +0.010
-0.158
1.5
(0.059)
13.0
± 0.20
(0.512
± 0.008)
20.2
(0.795)
12.4
+2.0
–0.0
(0.488) +0.078
-0.0
18.4
(0.724)
16mm
330
+0.25
–4.0
(12.992) +0.010
-0.158
1.5
(0.059)
13.0
± 0.20
(0.512
± 0.008)
20.2
(0.795)
16.4
+2.0
–0.0
(0.646) +0.078
-0.0
22.4
(0.882)
24mm
330
+0.25
–4.0
(12.992) +0.010
-0.158
1.5
(0.059)
13.0
± 0.20
(0.512
± 0.008)
20.2
(0.795)
24.4
+2.0
–0.0
(0.961) +0.078
-0.0
30.4
(1.197)
