UNISONIC TECHNOLOGIES CO., LTD

MBR5100

Preliminary

DIODE

www.unisonic.com.tw

1 of 3

QW-R202-057.a

5.0A SCHOTTKY BARRIER

RECTIFIER



DESCRIPTION

The UTC MBR5100 is a 5.0A schottky barrier rectifier, it uses

UTC’s advanced technology to provide the customers with high

surge capability, high efficiency, high current capability, low power

loss and low forward voltage drop, etc.

The UTC MBR5100 is suitable for free wheeling and polarity

protection, etc.

 FEATURES

* Low forward voltage drop, High Current Capability

* Low power loss, High efficiency

* High Surge Capability

*For Use in Low Voltage,High Frequency Inverters and Polarity

Protection Applications.



SYMBOL

DO-41

1

2



ORDERING INFORMATION

Ordering Number

Pin Assignment

Lead Free

Halogen Free

Package

1

2

Packing

MBR5100L-Z41-R

MBR5100G-Z41-R

DO-41

K

A

Tape Reel

Note: Pin Assignment: A: Anode

K: Cathode

(1) B: Tape Box, R: Tape Reel

(2) Z41: DO-41

(3) L: Lead Free, G: Halogen Free and Lead Free

MBR5100L-Z41-B

(1)Packing Type

(2)Package Type

(3)Green Package



MARKING

MBR5100

Date Code

L: Lead Free

G: Halogen Free

Cathode Band for uni-directional Only
