UNISONIC TECHNOLOGIES CO., LTD

U74LVC241

CMOS IC

www.unisonic.com.tw

1 of 5

Copyright © 2016 Unisonic Technologies Co., Ltd

QW-R126-030.A

OCTAL BUFFER/DRIVER WITH

3-STATE OUTPUTS



DESCRIPTION

The U74LVC241 contains two 4-bit line drivers with separate

output-enable(1 OE /2OE) inputs. When (1 OE /2OE) is low and high,

the device passes data from the A to the Y. When(1 OE /2OE) is

high and low, the outputs are in the high-impedance state.

The U74LVC241 can be used in a mixed 3.3V/5V system

environment. This device has power-down protective circuit,

preventing device destruction when it is powered down.



FEATURES

* Operate From 1.65V to 3.6V

* Input Accept Voltages to 5.5V

* Partial-Power-Down Mode Operation

* Max tpd is 6.1ns at 3.3V



ORDERING INFORMATION

Ordering Number

Package

Packing

U74LVC241G-S20-R

SOP-20

Tape Reel



MARKING
