7.3 x 6.8 x 3.0 mm

ASPI-7318

RoHS

Compliant

30332 Esperanza, Rancho Santa Margarita, California92688

Revised: 10.11.12

Visit www.abracon.com for Terms & Conditions of Sale

HIGH CURRENT SHIELDED POWER INDUCTOR

Pb

ABRACON IS

ISO9001:2008

CERTIFIED

REFLOW PROFILE:

Item

Ramp-up

Pre-heating

Reflow

Peak Temp

Cooling

Temperature Scope

Time spec.

-

60 ~ 180 sec

60 ~ 150 sec

20 ~ 40 sec

-

TAPE & REEL:

T= tape and reel (1,000pcs/reel)

Dimension: mm

D

E

W

P

P2

6.9 ref.

7.6 ref.

3.4 ref.

1.5 ref.

1.75 ref.

16 ref.

12 ref.

4 ref.

2 ref.

A

B

C

D

330

100 ref.

13 ref.

16 ref.
