background image
Data Sheet
HMC787A
Rev. 0 | Page 3 of 17
SPECIFICATIONS
TA = 25°C, IF = 100 MHz, LO = 17 dBm, and all measurements performed as downconverter, unless otherwise noted.
Table 1.
Parameter
Min
Typ
Max
Unit
FREQUENCY RANGE
RF
3
10
GHz
LO
3
10
GHz
IF
DC
4
GHz
LO DRIVE LEVEL
17
dBm
PERFORMANCE AT RF = 3 GHz to 9 GHz
Conversion Loss
9
11
dB
Single Sideband (SSB) Noise Figure
9
dB
Input Third-Order Intercept (IP3)
15
24
dBm
Input 1 dB Compression Point (P1dB)
17
dBm
Input Second-Order Intercept (IP2)
67
dB
RF to IF Isolation
15
26
dB
LO to RF Isolation
48
dB
LO to IF Isolation
35
43
dB
PERFORMANCE AT RF = 9 GHz to 10 GHz
Conversion Loss
9
11
dB
SSB Noise Figure
9
dB
Input IP3
15
24
dBm
Input P1dB
15
dBm
Input IP2
66
dB
RF to IF Isolation
15
26
dB
LO to RF Isolation
47
dB
LO to IF Isolation
25
42
dB
