Package Characteristics

All Typicals at TA = 25°C.

Parameter

Symbol

Min.

Typ.

Max.

Units

Test Conditions

Input-Output Insulation

II-O

µA

45% RH, t = 5 s

VI-O = 3 kV dc,

TA = 25°C

Input-Output Momentary

VISO

2500

Vrms

≤ 50%, t = 1 min.,

Withstand Voltage

TA = 25°C

Input-Output Resistance

RI-O

1012

Ω

VI-O = 500 V dc

Input-Output Capacitance

CI-O

0.6

f = 1 MHz, TA = 25°C

Notes:

1. tPHL propagation delay is measured from the 50% level on the risiing edge of the input pulse to the 2.5 V level of the falling edge

of the VO signal. tPLH propagation delay is measured from the 50% level on the falling edge of the input pulse to the 2.5 V level of

the rising edge of the VO signal.

2. PWD is defined as |tPHL - tPLH|.

3. tPSK is equal to the magnitude of the worst case difference in tPHL and/or tPLH that will be seen between units at any given

temperature within the recommended operating conditions.

4. CMH is the maximum tolerable rate of rise of the common mode voltage to assure that the output will remain in a high logic state.

5. CML is the maximum tolerable rate of fall of the common mode voltage to assure that the output will remain in a low logic state.
